use warnings;
use strict;
use List::Util qw(min max); # For Finding Max and Min in a list
use Data::Dumper qw(Dumper);
my $MethodChoice = 4;
# Saving Input Folder Name
my $InputFolderName = $ARGV[0];
# Giving path to LipidMaps Structure Drawing Tools
`export PATH="\$PATH:./bin/*_lipidmapstools/bin"`; # In bash/Linux
# Declaring Variables
my $VarString1;
my $VarString2;
my @VarList1;
my @VarList2;
my ($c1,$c2,$c3,$c4,$d1,$d2,$d3,$d4,$h1,$h2,$h_position,$db_positions1,$db_positions2,$db_positions3,$db_positions4,$i, $c_atoms, $d_bonds);
my @ClassList=(); # Initializing an array to store lipid classes
my @CentroidList=();
my @FAVarList2=(); # Probably not required. Included for Debugging
my $LipidName;
my $LipidNameCopy;
my $centroid;
my $SMILESlistFileName;
my $CentroidListFileName;
my @LipidNamesList=();
my $LipidClass;
my $LipidMapsProgramToUse;
my @Chains; # A Temporary list to store fatty acid chains
my @UnsupportedSpecies; # Array to store unused lipid abbreviations
my $TempFileName;
my $HighestConc; # Variable to store highest concentration observed in given set of files. Useful for plotting.
my @Lipid; # A list to store all lipid species
my @TempLipidsVarList1;
my @TempLipidsVarList2;
my @TempFileNameList;
my $LysoFlag=0; # If 0, its NOT a lyso species. If 1, its a lyso species.
# Obtaining Names of files present in InputFolder
my @FileNameList = `ls ./$InputFolderName`;
if (scalar(@FileNameList) == 0){ die "\nSomething is wrong, didnt find any files in $InputFolderName folder. Program terminating\n\n";}
# Removing known FileNames ("UserSMILES" and "FA" and "Cer") from @FileNameList
my @TempArray = (); my $file;
foreach $file (@FileNameList) {
chomp($file);
push (@TempArray, $file) if $file !~ m/(UserSMILES|FA|Cer)\.t(xt|ab)/;
}
@FileNameList = ();@FileNameList = @TempArray;
# Checking for duplicate FileNames in InputFolder
my @UniqFileNameList = uniq(@FileNameList);
if (scalar(@UniqFileNameList) != scalar(@FileNameList)) {
die "\nThere are ", scalar(@FileNameList) - scalar(@UniqFileNameList), " duplicate file names in your input folder.... program is terminating\n\n";
}
# Saving number of Input files
my $NumOfInputFiles = scalar(@FileNameList);
# Reading UserSMILES file
my %UserSMILES; # Hash table to store UserSMILES
my $count = 0 ;
open UserSMILES_FILE, "./$InputFolderName/UserSMILES.tab";
while (<UserSMILES_FILE>){ $count++;
$_ =~ s/\R//g; # Removing carraige return and/or new line character
@_ = split (/\t/,$_); if ( defined($_[0]) or defined($_[1]) ) {} else { die "Unable to parse UserSMILES file at line $count";}
chomp($_[1]);
$UserSMILES{$_[1]}="$_[0]";
}
close UserSMILES_FILE;
# Loading Fatty Acids from File
my @FAlist; # A list containing Fatty Acids
open FA_FILE, "./$InputFolderName/FA.tab" or die "Can\'t open \.\/$InputFolderName\/FA.tab \: $!";
while (<FA_FILE>){
$_ =~ s/\R//g; # Removing carraige return and/or new line character
chomp($_);
@_ = split("\t",$_);
push (@FAlist, [@_]);
}
close FA_FILE;
# Loading Sphingosine(s) from File
my @CerList; # A list containing Sphingosoine composition
open CER_FILE, "./$InputFolderName/Cer.txt" or die "Can\'t open \.\/$InputFolderName\/Cer.txt \: $!";
while (<CER_FILE>){
chomp($_);
$_ =~ s/\R//g;
push (@CerList, $_);
}
close CER_FILE;
#################################################
#1----------Reading Lipidome Data----------------
#################################################
my @SampleList;
my %DataTable = ();
if ((scalar (@FileNameList)) > 1) {# If multiple input files, read each file in InputFolder and make a combined list of lipid species
$HighestConc=0; # Variable to store highest concentration observed in given set of files. Useful for plotting.
foreach $TempFileName (@FileNameList){
@TempLipidsVarList1=();
@TempLipidsVarList2=();
open InFile, "./$InputFolderName/$TempFileName" or die "Can't open file $TempFileName in folder $InputFolderName : $!";
while (<InFile>){
$_ =~ s/\R//g; # Removing carraige return and/or new line character
@_ = split(/\t/,$_); # Separating LipidSpecies Names from their Concentrations
push @TempLipidsVarList1, $_[0];
# $_[0] =~ s/(\s|;|:|,)/_/g;
$DataTable{"$_[0]"}{"$TempFileName"} = $_[1]; # Hash of hash. Autovivification. $DataTable{Molecule Name}{Sample} = Molecule Concentration
chomp($_[1]);
if ($HighestConc < $_[1]) { $HighestConc = $_[1];}
}
close InFile;
# Checking if there are any duplicate entries in a given file.
@TempLipidsVarList2 = uniq(@TempLipidsVarList1);
if (scalar(@TempLipidsVarList2) != scalar(@TempLipidsVarList1)) {
die "\nThere are ", scalar(@TempLipidsVarList1) - scalar(@TempLipidsVarList2), " duplicate molecule names in file $TempFileName. Program terminating\n\n";
}
push @Lipid,@TempLipidsVarList1;
}
# Combining lipid species from all files into one single Duplicate-Free list.
@TempLipidsVarList2 = ();
@TempLipidsVarList2 = uniq(@Lipid);
@Lipid = ();
@Lipid = sort @TempLipidsVarList2; print "No. of unique lipid species = ", scalar(@Lipid), "\n";
my $fh; open $fh, "> ./$InputFolderName/LipidsList.txt"; print $fh join ("\n", @Lipid); close $fh;
# Writing combined data to a single file
open $fh, "> ./$InputFolderName/$InputFolderName.tab";
print $fh join ("\t", @FileNameList);
my ($MolName, $FileName);
foreach $MolName (@Lipid){
print $fh ("\n", $MolName, "\t");
@TempLipidsVarList2 = ();
foreach $FileName (@FileNameList) {
if (defined($DataTable{$MolName}{$FileName})) { push @TempLipidsVarList2, $DataTable{$MolName}{$FileName}; }
else { push @TempLipidsVarList2, "NA"; }
}
print $fh join ("\t", @TempLipidsVarList2);
}
close $fh;
# print "Check files"; <stdin>;
}
elsif ((scalar (@FileNameList)) == 1) { # If only one tab/space/comma delimited input file, read data file and make a list of lipid species, sample names
$TempFileName = $FileNameList[0];
$HighestConc=0; # Variable to store highest concentration observed in given set of files. Useful for plotting.
open my $fh, "./$InputFolderName/$TempFileName" or die "Can't open file $TempFileName in folder $InputFolderName : $!";
my @lines = map [ split(/[\t,\,]+/) ], <$fh>;
close $fh;
my $NumSamples = scalar @{$lines[0]}; # print "$NumSamples"; <stdin>;
my $NumLipids = ((scalar @lines)-1); # print "$NumLipids"; <stdin>;
for (my $i = 1; $i <= $NumLipids; $i++){
push @Lipid, @{$lines[$i]}[0];
} # print $Lipid[0], "\t", $Lipid[-1];<stdin>;
@{$lines[0]}[-1] =~ s/\R//g;
@SampleList = @{$lines[0]}; # print $FileNameList[0],"\t", $FileNameList[-1]; <stdin>;
# Checking if there are any duplicate lipid entries in a given file.
@TempLipidsVarList1 = uniq(@Lipid);
if (scalar(@TempLipidsVarList1) != scalar(@Lipid)) {
die "\nThere are ", scalar(@TempLipidsVarList1) - scalar(@Lipid), "\nDuplicate molecule names in file $TempFileName. Program terminating\n\n";
}
@Lipid = @TempLipidsVarList1;
# Checking if there are any duplicate sample entries in a given file.
@TempLipidsVarList1 = uniq(@SampleList);
if (scalar(@TempLipidsVarList1) != scalar(@SampleList)) {
die "\nThere are ", scalar(@TempLipidsVarList1) - scalar(@SampleList), "\nDuplicate sample/experiment names in file $TempFileName. Program terminating\n\n";
}
@SampleList = @TempLipidsVarList1;
# Obtaining highest concentration
my $j;
for ($i=1; $i<=$NumLipids; $i++) {
for ($j=1; $j<=$NumSamples; $j++) {
if (@{$lines[$i]}[$j] !~ m/NA/){
if (@{$lines[$i]}[$j] > $HighestConc){$HighestConc = @{$lines[$i]}[$j]; }
}
}
}
# print "\n\n\$HighestConc = $HighestConc"; <stdin>;
# Writing Lipidome data from each sample to a separate file
$j = 1; my $write2file; my $Filename;
foreach $Filename (@SampleList){
open $write2file, "> ./$InputFolderName/$Filename";
for ($i = 1; $i <= $NumLipids; $i++){
if (@{$lines[$i]}[$j] !~ /NA/){
@{$lines[$i]}[$j] =~ s/\R//g;
print $write2file @{$lines[$i]}[0], "\t", @{$lines[$i]}[$j];
print $write2file "\n" if ($i < $NumLipids);
}
}
close $write2file;
$j++;
} # print "\nCheck Files.."; <stdin>;
}
print "Highest conc = $HighestConc\n";
#################################################
#2---------Generate Lipid Structures-------------
#################################################
my ($PlasmogenFlag, $SN_Flag, $OH_Flag );
my ($dbp1, $dbp2);
open OutFile2, "> ./$InputFolderName/Isomers.txt" or die "Unable to open ./$InputFolderName/Isomers.txt file";
foreach (@Lipid){
exit_foreach_lipid_loop: {
$LipidName=$_;
chomp($LipidName);
print "Generating possible structures for $LipidName\n";
# Opening a file to write isomer possibilities for centroid determination
open OutFile1, "> ./$InputFolderName/OutFile1.txt";
$LipidClass = &Get_LipidClass ;
# print "Lipid Class = $LipidClass\n";# <stdin>;
$PlasmogenFlag = &CheckPlasmogen;
$SN_Flag = &Check_SN_composition;
$OH_Flag = &Get_OH_info_for_Ceramides; # Get information on hydroxylation state for Ceramides. Applicable only if SN1 and SN2 FA composition is not specified.
my $user_SMILES_found = &Search_UserSMILES;
if ($user_SMILES_found == 1){
close OutFile1;
last exit_foreach_lipid_loop;
}
elsif ($LipidClass !~ m/\b(PC|PA|PS|PI|PE|PG|DG|TG|TAG|DAG|CL|IPC|MIPC|MIP2C|Cer|CerP|PICer|HexCer|PECer|CerPE|LCB|LCBP|MIPCer|MIP2Cer|LPC|LPA|LPS|LPI|LPE|LPG|LIPC)\b/){
push @UnsupportedSpecies, $LipidName;
last exit_foreach_lipid_loop;
# print "\nCannot generate structure for this molecule..Press any key to coninue"; <stdin>;
}
push (@ClassList, $LipidClass);
$LysoFlag = &CheckForLyso; # This sub routine also changes the string $LipidClass
# print "\nLipid Class = $LipidClass\n\$PlasmogenFlag = $PlasmogenFlag\n\$SN_Flag = $SN_Flag\n\$LysoFlag = $LysoFlag\n\$OH_Flag = $OH_Flag\n";<stdin>;
# print "\nPlasmogenFlag = $PlasmogenFlag\n";
if (($SN_Flag == 1) or ($LysoFlag == 1)) {
&Parse_and_draw_Isomers;
}
else {
# Predict SN composition and draw PhosphoLipids and DG
if ($LipidClass =~ m/\b(PC|PA|PS|PI|PE|PG|DG)\b/){ # print "\nPredicting SN composition and drawing PC_DG...\n";
($c1, $c2, $d1, $d2, $dbp1, $dbp2) = &Predict_SN_and_draw_PL_DG($LipidName, $LipidClass);
}
# Predict SN composition and draw Ceramides
elsif ($LipidClass =~ m/\b(Cer|CerP|PICer|HexCer|PECer|MIPCer|MIP2Cer)\b/){ # print "\nPredicting SN composition and drawing Ceramides...\n";
($c1, $c2, $d1, $d2, $dbp1, $dbp2) = &Predict_SN_and_draw_Cer($LipidName, $LipidClass);
}
# Draw TG
elsif ($LipidClass =~ m/\bTG\b/){ # print "\nPredicting SN composition and drawing TG...\n";
($c1, $c2, $d1, $d2, $dbp1, $dbp2) = &Predict_SN_and_draw_TG($LipidName, $LipidClass);
}
# Draw CL
elsif ($LipidClass =~ m/\bCL\b/){ # print "\nPredicting SN composition and drawing CL...\n";
($c1, $c2, $d1, $d2, $dbp1, $dbp2) = &Predict_SN_and_draw_CL($LipidName, $LipidClass);
}
}
# Program design generates duplicates for Ceramides, PC/PE TAG etc. (TODO : Modify design so that duplicates are not generated)
# Deleting duplicates...
close OutFile1; # print "\nCheck OutFile1 and press any key to continue..."; <stdin>;
&DelDuplicates;
&FindCentroidIsomer;
}
}
&WriteLists2Files;
close OutFile2;
################################################################################
#3------------Calculating pair wise distances between lipid species-------------
################################################################################
my $CSVfilename = "$InputFolderName"."\.csv"; # print "./$InputFolderName/$CSVfilename";<stdin>;
my $LOGfilename = "$InputFolderName"."\.log";
my $ALNfilename = "$InputFolderName"."\.aln";
if ($MethodChoice==1){`perl ./bin/*m1.pl ./$InputFolderName/$SMILESlistFileName ./$InputFolderName/$CSVfilename ./$InputFolderName/$LOGfilename`;}
elsif ($MethodChoice==2){`python ./bin/*m2.py ./$InputFolderName/$SMILESlistFileName ./$InputFolderName/$CSVfilename ./$InputFolderName/$LOGfilename`;}
#elsif ($MethodChoice==3){`perl ./bin/*m3.pl ./$InputFolderName/$SMILESlistFileName ./$InputFolderName/$CSVfilename ./$InputFolderName/$LOGfilename`;}
elsif ($MethodChoice==4){`python ./bin/*m4.py ./$InputFolderName/$SMILESlistFileName ./$InputFolderName/$CSVfilename ./$InputFolderName/$LOGfilename`;}
elsif ($MethodChoice==5){`python ./bin/*m5.py ./$InputFolderName/$SMILESlistFileName ./bin/mat4 ./$InputFolderName/$CSVfilename ./$InputFolderName/$LOGfilename`;}
elsif ($MethodChoice==6){`perl ./bin/*m6.pl ./$InputFolderName/$SMILESlistFileName ./$InputFolderName/O2.aln ./$InputFolderName/$CSVfilename ./$InputFolderName/$LOGfilename`;
`rm ./$InputFolderName/O2.aln ./$InputFolderName/O2.aln_joined`;`mv ./$InputFolderName/O2.aln_joined_rearranged ./$InputFolderName/$ALNfilename`;
}
################################################################################
#4--------------------Performing Principal Component Analysis ------------------
################################################################################
my $PCAfilename = "$InputFolderName"."\.pca";
my $VariancePlotFileName = "$InputFolderName"."_VariancePlot"."\.pdf";
my @PCAcoordinates = `Rscript ./bin/121012_PCAfromCSV.R ./$InputFolderName/$CSVfilename ./$InputFolderName/$VariancePlotFileName ./$InputFolderName/$PCAfilename`;
chomp($PCAcoordinates[0]); #print "$PCAcoordinates[0] \n";
chomp($PCAcoordinates[1]); #print "$PCAcoordinates[1] \n";
chomp($PCAcoordinates[2]); #print "$PCAcoordinates[2] \n";
chomp($PCAcoordinates[3]); #print "$PCAcoordinates[3] \n $HighestConc \n"; <stdin>;
# print "\n\nCompleted PCA.. press any key to continue"; <stdin>;
################################################
#5---------Plot 2D and 3D Maps------------------
################################################
my @MultiPlotOutput=();
if (scalar (@FileNameList) == 1) { @FileNameList = (); @FileNameList = @SampleList; }
foreach $TempFileName (@FileNameList){
@MultiPlotOutput = `Rscript ./bin/130115_PCA_plot_150507Edit2.R "./$InputFolderName/$TempFileName" "./$InputFolderName/$InputFolderName\.pca" "./$InputFolderName/ClassList.txt" "./$InputFolderName/CentroidList.txt" "$PCAcoordinates[0]" "$PCAcoordinates[1]" "$PCAcoordinates[2]" "$PCAcoordinates[3]" "$HighestConc" "./$InputFolderName/$TempFileName"`;
# print @MultiPlotOutput;
}
# Combined Lipidome Plot
my $SVGfilename_2D = "$InputFolderName"."_2D\.svg";
my $SVGfilename_3D = "$InputFolderName"."_3D\.svg";
`Rscript ./bin/130124_CombinedLipidomePlot_150507Edit2.R "./$InputFolderName/$SVGfilename_2D" "./$InputFolderName/$PCAfilename" "./$InputFolderName/ClassList.txt" "./$InputFolderName/$SVGfilename_3D"`;
# Writing un-analyzed lipid species to <stdout>
print "\nUnused lipid abbreviations\n\n";
print join ("\n", @UnsupportedSpecies);
print "\n\n";
open my $fh, "> ./$InputFolderName/Unused_LipidAbbreviations.txt";
print $fh join ("\n", @UnsupportedSpecies);
close $fh;
################################################################################################
#6----------------Calculating Hausdroff distance and ploting Historgrams------------------------
################################################################################################
my $FileNameListRef = \@FileNameList;
my $FileNameList = join("XXXX", @FileNameList); # print "$FileNameList\n";
# Calculating Hausdroff distance and Average distance from PC1 PC2 Coordinates
`perl ./bin/130117_3_MaxDist_and_AvgDist_from_PC1_PC2.pl $InputFolderName $PCAfilename $FileNameList`;
# Calculating Hausdroff distance and Average distance from PC1 PC2 PC3 Coordinates
# $FileNameList = join("XXXX", @FileNameList);
`perl ./bin/130123_2_MaxDist_and_AvgDist_from_PC1_PC2_PC3.pl $PCAfilename $FileNameList $InputFolderName`;
# Calculating Hausdroff distance and Average distance from Similarity Scores
# $FileNameList = join("XXXX", @FileNameList);
`perl ./bin/140805_2_MaxDist_and_AvgDist_from_SimilarityScore.pl $CSVfilename $FileNameList $InputFolderName`;
# Creating Dendrograms as pdf - one per page
`Rscript ./bin/130117_Hdist2Dendro_150629_Edit.R $InputFolderName "./$InputFolderName/LUX_PC1_PC2.csv" "./$InputFolderName/LUX_PC1_PC2_PC3.csv" "./$InputFolderName/LUX_SimilarityScore.csv"`;
`rm ./$InputFolderName/CalcStats`;
###########################################
#----------- Sub-routine's ----------------
###########################################
sub uniq {
my @InArray = @_;
my @unique = ();
my %seen = ();
foreach my $elem ( @InArray ) {
next if $seen{ "$elem" }++;
push @unique, $elem;
}
return (@unique);
# return keys %{{ map { $_ => 1 } @_ }};
}
sub ModifySMILES {
$_ = $_[0];
$_ =~ s/\[C@\@H\]/C/g; # Removing steriochemistry for chiral carbon
$_ =~ s/\[C\@H\]/C/g;
$_ =~ s/\[C\@\@]/C/g;
$_ =~ s/\[C\@]/C/g;
$_ =~ s/\\//g; # Forward and backward slashes (meaning - cis - trans) are removed
$_ =~ s/\///g;
$_ =~ s/\[O\-\]/O/g; # Removing charges for Oxygen and Nitrogen atoms
$_ =~ s/\[N\+\]/N/g;
return ($_);
}
sub Search_UserSMILES {
my ($key,$LipidNameCopy);
my $count = 0;
$LipidNameCopy = $LipidName;
foreach $key (keys (%UserSMILES)) {
if ($key =~ m/\b\Q$LipidName\E\b/){ $count++;
# Add2Lists
$LipidNameCopy =~ s/(\s|;|:|,)/_/g;
push (@CentroidList, "$LipidNameCopy\tUserDefinedSMILES\t0");
push (@LipidNamesList, "$UserSMILES{$LipidName} $LipidNameCopy");
print "User defined SMILES taken for this molecule\n";
}
}
if ($count > 1){
print "\nFound duplicate molecule name in user defined SMILES list\n" and die "Program Terminating";
}
return ($count);
}
sub Get_LipidClass {
if ($LipidName =~ m/\s/){
@_ = split /(\s|_)/ , "$LipidName";
$LipidClass = $_[0]; #print "\$LipidClass at line 438 = $LipidClass";<stdin>;
}
}
sub CheckPlasmogen {
$PlasmogenFlag = 0;
if ($LipidName =~ m/_O/){ # print "Encountered O-";<stdin>;
$PlasmogenFlag = 1;
# $LipidName =~ s/\sO-/\_O/; # print $LipidClassDup;<stdin>;
}
if ($LipidName =~ m/_P/){
$PlasmogenFlag=2;
# $LipidName =~ s/\sP-/\_P/;
}
return ($PlasmogenFlag);
}
sub Check_SN_composition {
@_ = split /\s/ , "$LipidName";
my @SN_Chains = split /\// , $_[1] if (defined($_[1]));
if (defined($SN_Chains[1])){
$SN_Flag = 1;
}
else {
$SN_Flag = 0;
}
return ($SN_Flag);
}
sub CheckForLyso { # Finding out of a lipid species is a lyso molecule or not.
$LysoFlag = 0;
if ($LipidClass =~ m/^TAG/) {$LipidClass =~ s/TAG/TG/;}
elsif ($LipidClass =~ m/^DAG/) {$LipidClass =~ s/DAG/DG/;}
elsif ($LipidClass =~ m/^IPC/) {$LipidClass =~ s/IPC/PICer/;}
elsif ($LipidClass =~ m/^CerPE/) {$LipidClass =~ s/CerPE/PECer/;}
elsif ($LipidClass =~ m/^MIPC/) {$LipidClass =~ s/^MIPC/MIPCer/;}
elsif ($LipidClass =~ m/^M\(IP\)2C/) {$LipidClass =~ s/^M\(IP\)2C/MIP2Cer/;}
elsif ($LipidClass =~ m/^MIP2C/) {$LipidClass =~ s/^MIP2C/MIP2Cer/;}
elsif ($LipidClass =~ m/^LCB$/) {$LipidClass =~ s/LCB/Cer/; $LysoFlag=1;} # Its a lyso molecule
elsif ($LipidClass =~ m/^LCBP$/) {$LipidClass =~ s/LCBP/CerP/; $LysoFlag=1;} # Its a lyso molecule
elsif ($LipidClass =~ m/^LPC/) {$LipidClass =~ s/LPC/PC/; $LysoFlag=1;} # Its a lyso molecule
elsif ($LipidClass =~ m/^LPA/) {$LipidClass =~ s/LPA/PA/; $LysoFlag=1;} # Its a lyso molecule
elsif ($LipidClass =~ m/^LPS/) {$LipidClass =~ s/LPS/PS/; $LysoFlag=1;} # Its a lyso molecule
elsif ($LipidClass =~ m/^LPI/) {$LipidClass =~ s/LPI/PI/; $LysoFlag=1;} # Its a lyso molecule
elsif ($LipidClass =~ m/^LPE/) {$LipidClass =~ s/LPE/PE/; $LysoFlag=1;} # Its a lyso molecule
elsif ($LipidClass =~ m/^LIPC/) {$LipidClass =~ s/LIPC/PICer/; $LysoFlag=1;} # Its a lyso molecule
return ($LysoFlag);
}
sub Get_OH_info_for_Ceramides{
$OH_Flag = 0;
if ($LipidName =~ m/C_dt/) {
$OH_Flag = 3;
# $LipidClass =~ s/C_dt/C/;print "\n\$LipidClass = $LipidClass\n";
}
elsif ($LipidName =~ m/C_d/) {
$OH_Flag = 1;
# $LipidClass =~ s/C_d/C/;print "\n\$LipidClass = $LipidClass\n";
}
elsif ($LipidName =~ m/C_t/) {
$OH_Flag = 2;
# $LipidClass =~ s/C_t/C/;print "\n\$LipidClass = $LipidClass\n";
}
return ($OH_Flag);
}
sub Parse_and_draw_Isomers {
chomp($LipidName);
my $LipidNameCopy = $LipidName; # making a copy of lipid name to use it later (while generating CentroidList and SMILESlist files )
# Breaking lipid name to extract fatty acid chain information
my @LipidNameSplit;
if ($LipidName =~ m/\s/){ # Any lipid except sterols
@LipidNameSplit = split /\s/ , "$LipidName";
@Chains = split /\// , $LipidNameSplit[1];
}
if (($LipidClass =~ m/Cer/) and defined($LipidNameSplit[2])){ # print "\n \$LipidNameSplit\[2\] = $LipidNameSplit[2]\n";
if ($LipidNameSplit[2] == 1){$h2 = 1;}
elsif ($LipidNameSplit[2] == 2){$h2 = 2;}
else {print "\nUnknown text found in Lipid name\n" and die "Program Terminating !!";}
}
# Identifying number of c'atoms and d'bonds for (L)P(C|A|S|I|E|G) and DaG and Cer(P) CerPE HexCer
if ($LipidClass =~ m/\b(PC|PA|PS|PI|PE|PG|DG|Cer|CerP|PICer|HexCer|PECer|MIPCer|MIP2Cer)\b/){
# Splitting string "chain_1" to obtain 1) No. of carbon atoms 2) No. of double bonds
@_ = split("\:|\;", $Chains[0]);
($c1,$d1) = ($_[0], $_[1]); # print "\nc1 = $c1 and d1 = $d1\n";<stdin>;
if (defined($_[2]) and $LipidClass =~ m/Cer/) {
if ($_[2] == 1){$h1 = 0;}
elsif ($_[2] == 2){$h1 = 1;}
elsif ($_[2] == 3){$h1 = 2;}
else {print "\nOH position in LongChainBase is not parsed for molecule $LipidName\n" and die "Program Terminating\n";}
# print "\$_\[2\] = $_[2] \$h1 = $h1\n";
} # Applicable to Cermaides
if ($LysoFlag == 1) {
$c2 = 0;
$d2 = 0;
if ($LipidClass =~ m/Cer/){ $h2 = 0;}
}
# Splitting string "chain_2" to obtain 1) No. of carbon atoms 2) No. of double bonds
elsif ($LysoFlag == 0) {
@_ = split("\:|\;", $Chains[1]);
($c2,$d2) = ($_[0], $_[1]);
if (($LipidClass =~ m/Cer/) and defined($_[2])){ $h2 = $_[2];}
}
foreach (@FAlist){
if (($_->[0] == $c1) and ($_->[1] == $d1)) {
if($d1>0){
if (defined($_->[2])){
$db_positions1= $_->[2];
}
else {
$db_positions1="";
}
}else{
$db_positions1="";
}
foreach (@FAlist){
if (($_->[0] == $c2) and ($_->[1] == $d2)) {
if($d2>0){
if (defined($_->[2])){
$db_positions2= $_->[2];
}
else {
$db_positions2="";
}
}else{
$db_positions2="";
}
if ($LipidClass =~ m/DG/){
print OutFile1 "$LipidClass\($c1\:$d1$db_positions1\/$c2\:$d2$db_positions2\/0\:0\)\n";
print OutFile1 "$LipidClass\($c2\:$d2$db_positions2\/$c1\:$d1$db_positions1\/0\:0\)\n"; # Xchanging SN1 and SN2 positions
}elsif ($LipidClass =~ m/Cer/){
# print "c1 = $c1, d1 = $d1,db_positions1 = $db_positions1, c2 = $c2,d2 = $d2, db_positions2 = $db_positions2";
&GoToCer;
}else{
print OutFile1 "$LipidClass\($c1\:$d1$db_positions1\/$c2\:$d2$db_positions2\)\n";
# If its not a Lyso molecule, then exchange SN1 and SN2 positions
if ($LysoFlag != 1){
# Xchanging SN1 and SN2 positions
print OutFile1 "$LipidClass\($c2\:$d2$db_positions2\/$c1\:$d1$db_positions1\)\n";
}
}
}
}
}
}
}
# For TaG's only
elsif ($LipidClass =~ m/TG/){
# Splitting string "chain_1" to obtain 1) No. of carbon atoms 2) No. of double bonds
@_ = split("\:|\;", $Chains[0]);
($c1,$d1) = ($_[0], $_[1]);
# Splitting string "chain_2" to obtain 1) No. of carbon atoms 2) No. of double bonds
@_ = split("\:|\;", $Chains[1]);
($c2,$d2) = ($_[0], $_[1]);
# Splitting string "chain_2" to obtain 1) No. of carbon atoms 2) No. of double bonds
@_ = split("\:|\;", $Chains[2]);
($c3,$d3) = ($_[0], $_[1]);
foreach (@FAlist){
if (($_->[0] == $c1) and ($_->[1] == $d1)) {
if($d1>0){$db_positions1= $_->[2];}else{$db_positions1="";}
foreach (@FAlist){
if (($_->[0] == $c2) and ($_->[1] == $d2)) {
if($d2>0){$db_positions2= $_->[2];}else{$db_positions2="";}
foreach (@FAlist){
if (($_->[0] == $c3) and ($_->[1] == $d3)) {
if($d3>0){$db_positions3= $_->[2];}else{$db_positions3="";}
print OutFile1 "$LipidClass\($c1\:$d1$db_positions1\/$c2\:$d2$db_positions2\/$c3\:$d3$db_positions3\)\n";
print OutFile1 "$LipidClass\($c1\:$d1$db_positions1\/$c3\:$d3$db_positions3\/$c2\:$d2$db_positions2\)\n";
print OutFile1 "$LipidClass\($c2\:$d2$db_positions2\/$c1\:$d1$db_positions1\/$c3\:$d3$db_positions3\)\n";
print OutFile1 "$LipidClass\($c2\:$d2$db_positions2\/$c3\:$d3$db_positions3\/$c1\:$d1$db_positions1\)\n";
print OutFile1 "$LipidClass\($c3\:$d3$db_positions3\/$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2\)\n";
print OutFile1 "$LipidClass\($c3\:$d3$db_positions3\/$c2\:$d2$db_positions2\/$c1\:$d1$db_positions1\)\n";
}
}
}
}
}
}
}
# For CL's only
elsif ($LipidClass =~ m/CL/){
# Splitting string "chain_1" to obtain 1) No. of carbon atoms 2) No. of double bonds
@_ = split("\:|\;", $Chains[0]);
($c1,$d1) = ($_[0], $_[1]);
# Splitting string "chain_2" to obtain 1) No. of carbon atoms 2) No. of double bonds
@_ = split("\:|\;", $Chains[1]);
($c2,$d2) = ($_[0], $_[1]);
# Splitting string "chain_2" to obtain 1) No. of carbon atoms 2) No. of double bonds
@_ = split("\:|\;", $Chains[2]);
($c3,$d3) = ($_[0], $_[1]);
# Splitting string "chain_2" to obtain 1) No. of carbon atoms 2) No. of double bonds
@_ = split("\:|\;", $Chains[3]);
($c4,$d4) = ($_[0], $_[1]);
foreach (@FAlist){
if (($_->[0] == $c1) and ($_->[1] == $d1)) {
if($d1>0){$db_positions1= $_->[2];}else{$db_positions1="";}
foreach (@FAlist){
if (($_->[0] == $c2) and ($_->[1] == $d2)) {
if($d2>0){$db_positions2= $_->[2];}else{$db_positions2="";}
foreach (@FAlist){
if (($_->[0] == $c3) and ($_->[1] == $d3)) {
if($d3>0){$db_positions3= $_->[2];}else{$db_positions3="";}
foreach (@FAlist){
if (($_->[0] == $c4) and ($_->[1] == $d4)) {
if($d4>0){$db_positions4= $_->[2];}else{$db_positions4="";}
print OutFile1 "$LipidClass\(1\'\-\[$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2\]\, 3\'\-\[$c3\:$d3$db_positions3\/$c4\:$d4$db_positions4\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2\]\, 3\'\-\[$c4\:$d4$db_positions4\/$c3\:$d3$db_positions3\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c1\:$d1$db_positions1\/$c3\:$d3$db_positions3\]\, 3\'\-\[$c2\:$d2$db_positions2\/$c4\:$d4$db_positions4\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c1\:$d1$db_positions1\/$c3\:$d3$db_positions3\]\, 3\'\-\[$c4\:$d4$db_positions4\/$c2\:$d2$db_positions2\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c1\:$d1$db_positions1\/$c4\:$d4$db_positions4\]\, 3\'\-\[$c2\:$d2$db_positions2\/$c3\:$d3$db_positions3\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c1\:$d1$db_positions1\/$c4\:$d4$db_positions4\]\, 3\'\-\[$c3\:$d3$db_positions3\/$c2\:$d2$db_positions2\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c2\:$d2$db_positions2\/$c1\:$d1$db_positions1\]\, 3\'\-\[$c3\:$d3$db_positions3\/$c4\:$d4$db_positions4\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c2\:$d2$db_positions2\/$c1\:$d1$db_positions1\]\, 3\'\-\[$c4\:$d4$db_positions4\/$c3\:$d3$db_positions3\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c2\:$d2$db_positions2\/$c3\:$d3$db_positions3\]\, 3\'\-\[$c1\:$d1$db_positions1\/$c4\:$d4$db_positions4\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c2\:$d2$db_positions2\/$c3\:$d3$db_positions3\]\, 3\'\-\[$c4\:$d4$db_positions4\/$c1\:$d1$db_positions1\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c2\:$d2$db_positions2\/$c4\:$d4$db_positions4\]\, 3\'\-\[$c1\:$d1$db_positions1\/$c3\:$d3$db_positions3\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c2\:$d2$db_positions2\/$c4\:$d4$db_positions4\]\, 3\'\-\[$c3\:$d3$db_positions3\/$c1\:$d1$db_positions1\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c3\:$d3$db_positions3\/$c1\:$d1$db_positions1\]\, 3\'\-\[$c2\:$d2$db_positions2\/$c4\:$d4$db_positions4\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c3\:$d3$db_positions3\/$c1\:$d1$db_positions1\]\, 3\'\-\[$c4\:$d4$db_positions4\/$c2\:$d2$db_positions2\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c3\:$d3$db_positions3\/$c2\:$d2$db_positions2\]\, 3\'\-\[$c1\:$d1$db_positions1\/$c4\:$d4$db_positions4\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c3\:$d3$db_positions3\/$c2\:$d2$db_positions2\]\, 3\'\-\[$c4\:$d4$db_positions4\/$c1\:$d1$db_positions1\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c3\:$d3$db_positions3\/$c4\:$d4$db_positions4\]\, 3\'\-\[$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c3\:$d3$db_positions3\/$c4\:$d4$db_positions4\]\, 3\'\-\[$c2\:$d2$db_positions2\/$c1\:$d1$db_positions1\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c4\:$d4$db_positions4\/$c1\:$d1$db_positions1\]\, 3\'\-\[$c2\:$d2$db_positions2\/$c3\:$d3$db_positions3\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c4\:$d4$db_positions4\/$c1\:$d1$db_positions1\]\, 3\'\-\[$c3\:$d3$db_positions3\/$c2\:$d2$db_positions2\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c4\:$d4$db_positions4\/$c2\:$d2$db_positions2\]\, 3\'\-\[$c1\:$d1$db_positions1\/$c3\:$d3$db_positions3\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c4\:$d4$db_positions4\/$c2\:$d2$db_positions2\]\, 3\'\-\[$c3\:$d3$db_positions3\/$c1\:$d1$db_positions1\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c4\:$d4$db_positions4\/$c3\:$d3$db_positions3\]\, 3\'\-\[$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c4\:$d4$db_positions4\/$c3\:$d3$db_positions3\]\, 3\'\-\[$c2\:$d2$db_positions2\/$c1\:$d1$db_positions1\]\)\n";
}
}
}
}
}
}
}
}
}
}
sub GoToCer {
if (defined($h2)){
if ($h2==0){ $h_position = "";}
elsif ($h2==1){ $h_position = "(2OH)";}
elsif ($h2==2){ $h_position = "(2OH,4OH)";}
}
else {$h_position = "";} # print "\$LipidClass = $LipidClass";<stdin>;
if ($h1==0){ print OutFile1 "$LipidClass\(m$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2$h_position\)\n";}
elsif ($h1==1){ print OutFile1 "$LipidClass\(d$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2$h_position\)\n";}
elsif ($h1==2){ print OutFile1 "$LipidClass\(t$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2$h_position\)\n";}
}
sub Predict_SN_and_draw_PL_DG{
my $PlasmogenText;
if ($PlasmogenFlag == 0){ $PlasmogenText = "";}
elsif ($PlasmogenFlag == 1){ $PlasmogenText = "O-";}
elsif ($PlasmogenFlag == 2){ $PlasmogenText = "P-";}
# Breaking lipid name to extract fatty acid chain information
if ($LipidName =~ m/\s/){
@_ = split /\s/ , "$LipidName";
@Chains = split /\// , $_[1];
}
# Splitting string "chain_1" to obtain 1) No. of carbon atoms 2) No. of double bonds
@_ = split("\:|\;", $Chains[0]);
($c_atoms,$d_bonds) = ($_[0], $_[1]);
foreach (@FAlist){
($c1, $d1, $db_positions1) = ($_->[0], $_->[1], $_->[2]); # NoC1 = No. of Carbon atoms in FA 1
if (defined($db_positions1)){}else{$db_positions1="";}
foreach (@FAlist){
($c2, $d2, $db_positions2) = ($_->[0], $_->[1], $_->[2]);
if (defined($db_positions2)){}else{$db_positions2="";}
if ( (($c1+$c2)== $c_atoms) and (($d1+$d2) == $d_bonds) and ($c1!=0) and ($c1!=0) ) {
if ($LipidClass =~ m/DG/){
print OutFile1 "$LipidClass\($c1\:$d1$db_positions1\/$c2\:$d2$db_positions2\/0\:0\)\n";
print OutFile1 "$LipidClass\($c2\:$d2$db_positions2\/$c1\:$d1$db_positions1\/0\:0\)\n"; # Xchanging SN1 and SN2 positions
}else{
print OutFile1 "$LipidClass\($PlasmogenText$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2\)\n";
# If its not a Lyso molecule, then exchange SN1 and SN2 positions
if ($LysoFlag != 1){
# Xchanging SN1 and SN2 positions
print OutFile1 "$LipidClass\($PlasmogenText$c2\:$d2$db_positions2\/$c1\:$d1$db_positions1\)\n";
}
}
}
}
}
}
sub Predict_SN_and_draw_TG{
# Breaking lipid name to extract fatty acid chain information
if ($LipidName =~ m/\s/){
@_ = split /\s/ , "$LipidName";
@Chains = split /\// , $_[1];
}
# Splitting string "chain_1" to obtain 1) No. of carbon atoms 2) No. of double bonds
@_ = split("\:|\;", $Chains[0]);
($c_atoms,$d_bonds) = ($_[0], $_[1]);
foreach (@FAlist){
($c1, $d1, $db_positions1) = ($_->[0], $_->[1], $_->[2]); # NoC1 = No. of Carbon atoms in FA 1
if (defined($db_positions1)){}else{$db_positions1="";}
foreach (@FAlist){
($c2, $d2, $db_positions2) = ($_->[0], $_->[1], $_->[2]);
if (defined($db_positions2)){}else{$db_positions2="";}
foreach (@FAlist){
($c3, $d3, $db_positions3) = ($_->[0], $_->[1], $_->[2]);
if (defined($db_positions3)){}else{$db_positions3="";}
if ( (($c1+$c2+$c3)== $c_atoms) and (($d1+$d2+$d3) == $d_bonds) and ($c1!=0) and ($c2!=0) and ($c3!=0) ) {
print OutFile1 "$LipidClass\($c1\:$d1$db_positions1\/$c2\:$d2$db_positions2\/$c3\:$d3$db_positions3\)\n";
print OutFile1 "$LipidClass\($c1\:$d1$db_positions1\/$c3\:$d3$db_positions3\/$c2\:$d2$db_positions2\)\n";
print OutFile1 "$LipidClass\($c2\:$d2$db_positions2\/$c1\:$d1$db_positions1\/$c3\:$d3$db_positions3\)\n";
print OutFile1 "$LipidClass\($c2\:$d2$db_positions2\/$c3\:$d3$db_positions3\/$c1\:$d1$db_positions1\)\n";
print OutFile1 "$LipidClass\($c3\:$d3$db_positions3\/$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2\)\n";
print OutFile1 "$LipidClass\($c3\:$d3$db_positions3\/$c2\:$d2$db_positions2\/$c1\:$d1$db_positions1\)\n";
}
}
}
}
}
sub Predict_SN_and_draw_CL{
# Breaking lipid name to extract fatty acid chain information
if ($LipidName =~ m/\s/){
@_ = split /\s/ , "$LipidName";
@Chains = split /\// , $_[1];
}
# Splitting string "chain_1" to obtain 1) No. of carbon atoms 2) No. of double bonds
@_ = split("\:|\;", $Chains[0]);
($c_atoms,$d_bonds) = ($_[0], $_[1]);
foreach (@FAlist){
($c1, $d1, $db_positions1) = ($_->[0], $_->[1], $_->[2]); # NoC1 = No. of Carbon atoms in FA 1
if (defined($db_positions1)){}else{$db_positions1="";}
foreach (@FAlist){
($c2, $d2, $db_positions2) = ($_->[0], $_->[1], $_->[2]);
if (defined($db_positions2)){}else{$db_positions2="";}
foreach (@FAlist){
($c3, $d3, $db_positions3) = ($_->[0], $_->[1], $_->[2]);
if (defined($db_positions3)){}else{$db_positions3="";}
foreach (@FAlist){
($c4, $d4, $db_positions4) = ($_->[0], $_->[1], $_->[2]);
if (defined($db_positions4)){}else{$db_positions4="";}
if ( (($c1+$c2+$c3+$c4)== $c_atoms) and (($d1+$d2+$d3+$d4) == $d_bonds) and ($c1!=0) and ($c2!=0) and ($c3!=0) and ($c4!=0)) {
print OutFile1 "$LipidClass\(1\'\-\[$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2\]\, 3\'\-\[$c3\:$d3$db_positions3\/$c4\:$d4$db_positions4\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2\]\, 3\'\-\[$c4\:$d4$db_positions4\/$c3\:$d3$db_positions3\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c1\:$d1$db_positions1\/$c3\:$d3$db_positions3\]\, 3\'\-\[$c2\:$d2$db_positions2\/$c4\:$d4$db_positions4\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c1\:$d1$db_positions1\/$c3\:$d3$db_positions3\]\, 3\'\-\[$c4\:$d4$db_positions4\/$c2\:$d2$db_positions2\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c1\:$d1$db_positions1\/$c4\:$d4$db_positions4\]\, 3\'\-\[$c2\:$d2$db_positions2\/$c3\:$d3$db_positions3\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c1\:$d1$db_positions1\/$c4\:$d4$db_positions4\]\, 3\'\-\[$c3\:$d3$db_positions3\/$c2\:$d2$db_positions2\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c2\:$d2$db_positions2\/$c1\:$d1$db_positions1\]\, 3\'\-\[$c3\:$d3$db_positions3\/$c4\:$d4$db_positions4\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c2\:$d2$db_positions2\/$c1\:$d1$db_positions1\]\, 3\'\-\[$c4\:$d4$db_positions4\/$c3\:$d3$db_positions3\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c2\:$d2$db_positions2\/$c3\:$d3$db_positions3\]\, 3\'\-\[$c1\:$d1$db_positions1\/$c4\:$d4$db_positions4\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c2\:$d2$db_positions2\/$c3\:$d3$db_positions3\]\, 3\'\-\[$c4\:$d4$db_positions4\/$c1\:$d1$db_positions1\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c2\:$d2$db_positions2\/$c4\:$d4$db_positions4\]\, 3\'\-\[$c1\:$d1$db_positions1\/$c3\:$d3$db_positions3\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c2\:$d2$db_positions2\/$c4\:$d4$db_positions4\]\, 3\'\-\[$c3\:$d3$db_positions3\/$c1\:$d1$db_positions1\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c3\:$d3$db_positions3\/$c1\:$d1$db_positions1\]\, 3\'\-\[$c2\:$d2$db_positions2\/$c4\:$d4$db_positions4\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c3\:$d3$db_positions3\/$c1\:$d1$db_positions1\]\, 3\'\-\[$c4\:$d4$db_positions4\/$c2\:$d2$db_positions2\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c3\:$d3$db_positions3\/$c2\:$d2$db_positions2\]\, 3\'\-\[$c1\:$d1$db_positions1\/$c4\:$d4$db_positions4\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c3\:$d3$db_positions3\/$c2\:$d2$db_positions2\]\, 3\'\-\[$c4\:$d4$db_positions4\/$c1\:$d1$db_positions1\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c3\:$d3$db_positions3\/$c4\:$d4$db_positions4\]\, 3\'\-\[$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c3\:$d3$db_positions3\/$c4\:$d4$db_positions4\]\, 3\'\-\[$c2\:$d2$db_positions2\/$c1\:$d1$db_positions1\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c4\:$d4$db_positions4\/$c1\:$d1$db_positions1\]\, 3\'\-\[$c2\:$d2$db_positions2\/$c3\:$d3$db_positions3\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c4\:$d4$db_positions4\/$c1\:$d1$db_positions1\]\, 3\'\-\[$c3\:$d3$db_positions3\/$c2\:$d2$db_positions2\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c4\:$d4$db_positions4\/$c2\:$d2$db_positions2\]\, 3\'\-\[$c1\:$d1$db_positions1\/$c3\:$d3$db_positions3\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c4\:$d4$db_positions4\/$c2\:$d2$db_positions2\]\, 3\'\-\[$c3\:$d3$db_positions3\/$c1\:$d1$db_positions1\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c4\:$d4$db_positions4\/$c3\:$d3$db_positions3\]\, 3\'\-\[$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2\]\)\n";
print OutFile1 "$LipidClass\(1\'\-\[$c4\:$d4$db_positions4\/$c3\:$d3$db_positions3\]\, 3\'\-\[$c2\:$d2$db_positions2\/$c1\:$d1$db_positions1\]\)\n";
}
}
}
}
}
}
sub Predict_SN_and_draw_Cer {
my $total_OH_in_cer; # Total number of hydroxylations in the ceramide molecule. Andrej Drosophila Lipidome data uses this format
# Breaking lipid name to extract fatty acid chain information
my @LipidNameSplit;
if ($LipidName =~ m/\s/){ # Any lipid except sterols
@LipidNameSplit = split /\s/ , "$LipidName";
@Chains = split /\// , $LipidNameSplit[1];
}
if (($LipidClass =~ m/Cer/) and defined($LipidNameSplit[2])){ # Applicable for Howard's yeastlipidome data. This parsing rule minimises complexity in nomencature. Not recommened
# print "\n \$LipidNameSplit\[2\] = $LipidNameSplit[2]\n";
if ($LipidNameSplit[2] == 1){$h2 = 1;}
elsif ($LipidNameSplit[2] == 2){$h2 = 2;}
else {print "\nUnknown text found in Lipid name\n" and die "Program Terminating !!";}
}
# Splitting string "chain_1" to obtain 1) No. of carbon atoms 2) No. of double bonds
@_ = split("\:|\;", $Chains[0]);
($c_atoms,$d_bonds) = ($_[0], $_[1]);
if (defined ($_[2])) { # Applicable for Andrej's Drosophila lpidome data ONLY
$total_OH_in_cer = $_[2]; # Total number of hydroxylations in the ceramide molecule. Andrej Drosophila Lipidome data uses this format
# For Cer/CerPE/HexCer only...
if ($LipidClass =~ m/(Cer|PECer|HexCer)/){ # print "Writing possiblities for Cer/CerPE...";<stdin>;
$LipidClass =~ s/HexCer/GalCer/; # Giving Galactosyl Ceramide as one possibility for HexCer
foreach (@CerList){
$c1 = $_; # print "\n\$c1 = $c1..\n";
$d1 = "0";
$db_positions1 = "";
foreach (@FAlist){
($c2, $d2, $db_positions2) = ($_->[0], $_->[1], $_->[2]); # NoC1 = No. of Carbon atoms in FA 1
if (defined($db_positions2)) {} else {$db_positions2="";}
if ((($c1+$c2)== $c_atoms) and ($d1+$d2 == $d_bonds) and ($c1!=0) and ($c2!=0)) {
if ($total_OH_in_cer == 2) {
# If there are two hydroxylations, then two possibilities are taken into consideration
# 1. Both in head group (3,4)
print OutFile1 "$LipidClass\(d$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2\)\n";
# Giving Glucosyl Ceramide as second possibility for HexCer
if ($LipidClass =~ m/GalCer/){
print OutFile1 "GlcCer\(d$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2\)\n";
}
# 2. One in head group (3); second in Fatty acid group (at 2 nd carbon atom from COOH end)
print OutFile1 "$LipidClass\(m$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2\(2OH\)\)\n";
# Giving Glucosyl Ceramide as second possibility for HexCer
if ($LipidClass =~ m/GalCer/){
print OutFile1 "GlcCer\(m$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2\(2OH\)\)\n";
}
}
elsif ($total_OH_in_cer == 3) {
# If there are two hydroxylations, then the positions of these hydroxylations are fixed
# two in Head group ; one in F'Acid chain
print OutFile1 "$LipidClass\(d$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2\(2OH\)\)\n";
# Giving Glucosyl Ceramide as second possibility for HexCer
if ($LipidClass =~ m/GalCer/){
print OutFile1 "GlcCer\(d$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2\(2OH\)\)\n";
}
}
}
}
}
}
else {
print "\nUnknown LipidClass $LipidClass in molecule $LipidName" and die "Program Terminating";
}
}
else { # print "I am at line 965\n";
foreach (@CerList){
$c1 = $_; # print "\n\$c1 = $c1..\n";
$d1 = "0";
$db_positions1 = "";
foreach (@FAlist){
($c2, $d2, $db_positions2) = ($_->[0], $_->[1], $_->[2]); # NoC1 = No. of Carbon atoms in FA 1
if (defined($db_positions2)) {} else {$db_positions2="";}
if ((($c1+$c2)== $c_atoms) and ($d1+$d2 == $d_bonds) and ($c1!=0) and ($c2!=0)) {
if ($OH_Flag == 0){ # $OH_Flag here is similar to $h1. $OH_Flag and $h1 represent no. of hydroxylations in LongChainBase
print OutFile1 "$LipidClass\(m$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2$h_position\)\n";
}
elsif ($OH_Flag==1){ print OutFile1 "$LipidClass\(d$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2$h_position\)\n";}
elsif ($OH_Flag==2){ print OutFile1 "$LipidClass\(t$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2$h_position\)\n";}
elsif ($OH_Flag==3){
print OutFile1 "$LipidClass\(t$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2\)\n";
print OutFile1 "$LipidClass\(d$c1\:$d1$db_positions1\/$c2\:$d2$db_positions2$h_position\)\n";
}
}
}
}
}
}
sub DelDuplicates {
open FILEA, "./$InputFolderName/OutFile1.txt" or die "\n$! Unable to open OutFile1.txt\n";
my @list3=<FILEA>;
close FILEA;
@list3 = uniq(@list3);
open FILEB, "> ./$InputFolderName/OutFile1.txt";
print FILEB @list3;
close FILEB;
}
sub FindCentroidIsomer {
# Generating MOL-MOL file for all possible structures using LipidMaps Structure Drawing Tools
if ($LipidClass =~ m/(TG|DG)/){ $LipidMapsProgramToUse = "GLStrGen.pl";}
elsif ($LipidClass =~ m/(Cer|PICer|PECer|HexCer|MIPCer|MIP2Cer)/){ $LipidMapsProgramToUse = "SPStrGen.pl";}
elsif ($LipidClass =~ m/(PC|PA|PS|PI|PE|PG)/){ $LipidMapsProgramToUse = "GPStrGen.pl";}
elsif ($LipidClass =~ m/CL/){ $LipidMapsProgramToUse = "CLStrGen.pl";} # print "\n\$LipidMapsProgramToUse = $LipidMapsProgramToUse"; <stdin>;
else {print "\nI could not figure out the LipidMaps Structure Drawing program to use\n" and die "Program Terminating\n";}
`perl ./bin/*_lipidmapstools/bin/$LipidMapsProgramToUse -m AbbrevFileName ./$InputFolderName/OutFile1.txt -r ./$InputFolderName/OutFile1`;
# `mv OutFile1.sdf ./$InputFolderName/OutFile1.sdf`;
# Converting MOL-MOL structures to SMILES using "OpenBabel : Molecule Conversion package"
`babel -isdf ./$InputFolderName/OutFile1.sdf -osmi ./$InputFolderName/OutFile1.smi -d -b `; # print "check 01.smi file";<stdin>;
# Finding Centroid structure
# Changing molecule names (because of limitation in ASCII characters that can be used as Molecule names
open OutFile3, "./$InputFolderName/OutFile1.smi";
open O2, "> ./$InputFolderName/O2.smi";
$i=0;
@VarList1=(); # Array to store SMILES strings
@VarList2=(); # Array to store Molecule names
while (<OutFile3>){
($VarString1, $VarString2) = split("\t", $_);
$VarString1 = &ModifySMILES($VarString1);
push (@VarList1, "$VarString1");
chomp($VarString2);
push (@VarList2, "$VarString2");
print O2 "$VarString1 $i\n";
$i++;
}
close O2; # print "check 02.smi file";<stdin>;
close OutFile3;
# If there are no possible sructures..
if ($i == 0){
print STDERR "\nUnable to generate structures from Fatty Acid possibilities defined in ./$InputFolderName/FA file\n" ;
push @UnsupportedSpecies, $LipidName;
# `rm ./$InputFolderName/OutFile1.sdf ./$InputFolderName/OutFile1.smi ./$InputFolderName/OutFile1.txt ./$InputFolderName/O2.smi`;
}
# If there is only one possible structure for a given lipid species, take that structure as default centroid structure
elsif ($i == 1) {$centroid = 0;}
# If there is only TWO possible structure for a given lipid species, choose first one as centroid structure
elsif ($i == 2) {$centroid = 0;}
# If there is only TWO possible structure for a given lipid species, randomly choose one of them as centroid structure
# elsif ($i == 2) {$centroid = int(rand(2));}
# If there are more than TWO possible structures, find centroid structure using any of the six similarity scoring methods
else {
if ($MethodChoice==1){`perl ./bin/*m1.pl ./$InputFolderName/O2.smi ./$InputFolderName/O2.csv ./$InputFolderName/O2.log`;}
elsif ($MethodChoice==2){`python ./bin/*m2.py ./$InputFolderName/O2.smi ./$InputFolderName/O2.csv ./$InputFolderName/O2.log`;}
#elsif ($MethodChoice==3){`perl ./bin/*m3.pl ./$InputFolderName/O2.smi ./$InputFolderName/O2.csv ./$InputFolderName/O2.log`;}
elsif ($MethodChoice==4){`python ./bin/*m4.py ./$InputFolderName/O2.smi ./$InputFolderName/O2.csv ./$InputFolderName/O2.log`;}
elsif ($MethodChoice==5){`python ./bin/*m5.py ./$InputFolderName/O2.smi ./bin/mat4 ./$InputFolderName/O2.csv ./$InputFolderName/O2.log`;}
elsif ($MethodChoice==6){`perl ./bin/*m6.pl ./$InputFolderName/O2.smi ./$InputFolderName/O2.aln ./$InputFolderName/O2.csv ./$InputFolderName/O2.log`;
`rm ./$InputFolderName/O2.aln ./$InputFolderName/O2.aln_joined ./$InputFolderName/O2.aln_joined_rearranged`;}
# print "check csv file";<stdin>;
# input *.csv file into centroid.pl program
# get the center molecule and it's SMILES
# $centroid =`echo "./$InputFolderName/O2.csv" | perl ./bin/centroid2.pl;`; print "$centroid";<stdin>;
$centroid =`perl ./bin/centroid2.pl ./$InputFolderName/O2.csv`; # print "\$centroid = $centroid";
# Deleting temporary files..
`rm ./$InputFolderName/O2.csv`;
}
# Deleting temporary files..
`rm ./$InputFolderName/OutFile1.sdf ./$InputFolderName/OutFile1.smi ./$InputFolderName/OutFile1.txt ./$InputFolderName/O2.smi`;
if ($i != 0) {&Add2Lists;}
}
sub Add2Lists {
# To CentroidList
$LipidName =~ s/(\s|;|:|,)/_/g;
$_ = scalar(@VarList2);
push (@CentroidList, "$LipidName\t$VarList2[$centroid]\t$_");
print OutFile2 "$LipidName\t";
print OutFile2 join ("\t", @VarList2);
print OutFile2 "\n";
# To SMILESlist
push (@LipidNamesList, "$VarList1[$centroid] $LipidName");
}
sub WriteLists2Files{
# Write CentroidList to File
$CentroidListFileName = "CentroidList\.txt";
open O3, "> ./$InputFolderName/$CentroidListFileName" or die "Unable to open ./$InputFolderName/$CentroidListFileName file";
print O3 join ("\n", @CentroidList);
close O3;
# Write SMILESlist to File
$SMILESlistFileName = "SMILESlist\.smi";
open O4, "> ./$InputFolderName/$SMILESlistFileName";
print O4 join ("\n", @LipidNamesList);
close O4;
# Write ClassList to File
@ClassList = uniq(@ClassList); # removing duplicate classes
open O5, "> ./$InputFolderName/ClassList.txt";
print O5 join ("\n", @ClassList);
print O5 "\n";
close O5;
}
__END__
